Model AF-10 ................... $769.00 Add To Cart Optional three-point lift only for AF-10 and AF-5 harrows.
Model AF-3P. |
 |
Model AF-5.................. $459.00 Add To Cart |
 |
Model AF-5 and AF-5C Combo $700.00 Add To Cart Wheel carrier for AF-5 only: Model AF-5C $249.00 Add To Cart |
Flexible Tine Harrow
The most useful and economical maintenance tool you can own.
Use for rings and arenas, pastures and paddocks, and general
farm and ranch maintenance management.
The Country Harrow handles many of your chores with ease. Pictured
here with "tines down", it's breaking up manure and
dethatching all in one process, helping to control parasites
while raking and aerifying the grasses for healthy and vigorous
growth.
A Valuable Benefit of the Country Harrow is it's Simple Depth
Control Feature that lets You Accomplish a Variety of Tasks.
Within just a few minutes the harrow can be adjusted to be pulled
in the aggressive, less aggressive or inverted mode, or a combination
of those modes.
Through a system of attaching hooks, the individual component
can be towed from the front or rear hooks, for instance, in the
most aggressive position, ground contact will make the tine stand
upright. However, when the drawbar is placed at the opposite
end, ground contact will then make the tines less aggressive.
To achieve a combination mode, e.g. Fluff with the front component
and firm with the rear component, you need only to unhook the
rear most component and reverse its direction of travel or perhaps
turn upside down to Firm and Smooth.
 |
AGGRESSIVE MODE Tines thoroughly work ground/soils. |
 |
LESS AGGRESSIVE MODE Tines angled back to lightly work and level ground/soils. |
 |
COMBINATION MODE Front Component works soils, rear component levels. |
 |
INVERTED / SMOOTHING MODE Entire harrow turned up-side down to level and firm. |
While conditions do vary, you will need approximately two tractor horsepower per foot of harrow width. i.e., a 10 HP garden tractor will pull a 4 ft. wide Country harrow. A 15 HP tractor will pull a 6 ft. wide country harrow. It is good to consider what materials you will be working in. e.g. a sandy arena will provide less tire traction than perhaps a pasture field.
 |
Model ...Width... Weight L-4 .......4 FT .....137 LBS $549.00 Add To Cart L-6 .......6 FT .....214 LBS $859.00 Add To Cart L-8 .......8 FT .....266 LBS $989.00 Add To Cart |
|
|
Model ...Width... Weight L-10 ...10 FT .....368 LBS $1309.00 Add To Cart L-12 ...12 FT .....413 LBS $1629.00 Add To Cart |
 |
For those who wish to transport, we offer a three point hitch carrier for widths of 6 ft., 8 ft., 10 ft. and 12 ft. wide Country harrows. LL-6 ....6 FT - 3 PT LIFT 128
LBS $779.00 Add
To Cart |
